ALL VERSIONS



G950F

G950FD

G950U

G950A

G950P

G950T

G950V

G950R4

G950W

G9500

Versions: G950F (Europe, Global Single-SIM); G950FD (Global Dual-SIM); G950U (USA Unlocked); G950A (AT&T); G950P (Sprint); G950T (T-Mobile); G950V (Verizon); G950R4 (US Cellular); G950W (Canada); G950S/G950K/G950L (South Korea); G9500 (China)

NETWORK	Technology	GSM / HSPA / LTE
	2G bands	GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only)
	3G bands	HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
	4G bands	LTE band 1(2100), 2(1900), 3(1800), 4(1700/2100), 5(850), 7(2600), 8(900), 12(700), 13(700), 17(700), 18(800), 19(800), 20(800), 25(1900), 26(850), 28(700), 32(1500), 66(1700/2100), 38(2600), 39(1900), 40(2300), 41(2500)
	Speed	HSPA 42.2/5.76 Mbps, LTE-A (5CA) Cat16 1024/150 Mbps

LAUNCH	Announced	2017, March
	Status	Available. Released 2017, April

BODY	Dimensions	148.9 x 68.1 x 8 mm (5.86 x 2.68 x 0.31 in)
	Weight	155 g (5.47 oz)
	Build	Glass front (Gorilla Glass 5), glass back (Gorilla Glass 5), aluminum frame
	SIM	Single SIM (Nano-SIM) or Hybrid Dual SIM (Nano-SIM, dual stand-by)
		Samsung Pay (Visa, MasterCard certified) IP68 dust/water resistant (up to 1.5m for 30 mins)

DISPLAY	Type	Super AMOLED capacitive touchscreen, 16M colors
	Size	5.8 inches, 84.8 cm2 (~83.6% screen-to-body ratio)
	Resolution	1440 x 2960 pixels, 18.5:9 ratio (~570 ppi density)
	Protection	Corning Gorilla Glass 5
		HDR10 3D Touch (home button only) Always-on display

PLATFORM	OS	Android 7.0 (Nougat), upgradable to Android 9.0 (Pie); One UI
	Chipset	Exynos 8895 (10 nm) - EMEA Qualcomm MSM8998 Snapdragon 835 (10 nm) - USA & China
	CPU	Octa-core (4x2.3 GHz Mongoose M2 & 4x1.7 GHz Cortex-A53) - EMEA Octa-core (4x2.35 GHz Kryo & 4x1.9 GHz Kryo) - USA & China
	GPU	Mali-G71 MP20 - EMEA Adreno 540 - USA & China

MEMORY	Card slot	microSDXC (uses shared SIM slot) - dual SIM model only
	Internal	64GB 4GB RAM
		UFS 2.0 or UFS 2.1

MAIN CAMERA	Single	12 MP, f/1.7, 26mm (wide), 1/2.55", 1.4µm, dual pixel PDAF, OIS
	Features	LED flash, auto-HDR, panorama
	Video	2160p@30fps, 1080p@30/60fps, 720p@240fps, HDR, dual-video rec., stereo sound rec., gyro-EIS, OIS

SELFIE CAMERA	Single	8 MP, f/1.7, 25mm (wide), 1/3.6", 1.22µm, AF
	Features	Dual video call, Auto-HDR
	Video	1440p@30fps

SOUND	Loudspeaker	Yes
	3.5mm jack	Yes
		32-bit/384kHz audio

COMMS	WLAN	Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, hotspot
	Bluetooth	5.0, A2DP, LE, aptX
	GPS	Yes, with A-GPS, GLONASS, BDS, GALILEO
	NFC	Yes
	Radio	No
	USB	3.1, Type-C 1.0 reversible connector

FEATURES	Sensors	Iris scanner, fingerprint (rear-mounted), accelerometer, gyro, proximity, compass, barometer, heart rate, SpO2
		Samsung DeX (desktop experience support) ANT+ Bixby natural language commands and dictation

BATTERY		Non-removable Li-Ion 3000 mAh battery (11.55 Wh)
	Charging	Fast battery charging 15W (Quick Charge 2.0) Qi/PMA wireless charging (market dependent)
	Talk time	Up to 20 h (3G)
	Music play	Up to 67 h

MISC	Colors	Midnight Black, Orchid Gray, Arctic Silver, Coral Blue, Maple Gold, Rose Pink, Burgundy Red
	Models	SM-G950FD, SM-G950W, SM-G950S, SM-G950K, SM-G950L, SM-G9500, SM-G950A, SM-G950P, SM-G950T, SM-G950U, SM-G950V, SM-G950F, SM-G950U1, SM-G950N, SC-02J, SCV36, SM-G950, G950F
	SAR	0.44 W/kg (head)     0.75 W/kg (body)
	SAR EU	0.32 W/kg (head)     1.27 W/kg (body)

TESTS	Performance	Basemark OS II: 3272 / Basemark OS II 2.0: 3376 Basemark X: 42370
	Display	Contrast ratio: Infinite (nominal), 4.768 (sunlight)
	Camera	Photo / Video
	Loudspeaker	Voice 66dB / Noise 70dB / Ring 72dB
	Audio quality	Noise -92.5dB / Crosstalk -92.8dB
	Battery life	Endurance rating 84h
